Olivine–pigeoniteLow-Ca clinopyroxene, (Ca,Mg,Fe)SiO3, found as a major mineral in eucrites and shergottites. In order to be considered pigeonite, the clinopyroxene must contain 5 to 20 mol % of calcium (Wo5 - 20). Chondrites of petrologic types 4 and below contain significant low-Ca clinopyroxene. During metamorphism to higher temperatures, all existing
Found January 8, 2004
19° 45.4′ N., 54° 56.2′ W. A single complete stone weighing 1,063 g was found in Oman by Mike Farmer. Coincidentally, this achondriteAn achondrite is a type of stony meteorite whose precursor was of chondritic origin and experienced metamorphic and igneous processes. They have a planetary or differentiated asteroidal origin where the chondritic parent body reached a sufficient size that through heating due to radioactive decay of 26Al (aluminum isotope) and gravitational Click on Term to Read More was found only ~30 m from an oriented chondriteChondrites are the most common meteorites accounting for ~84% of falls. Chondrites are comprised mostly of Fe- and Mg-bearing silicate minerals (found in both chondrules and fine grained matrix), reduced Fe/Ni metal (found in various states like large blebs, small grains and/or even chondrule rims), and various refractory inclusions (such Click on Term to Read More. Analysis and classification was completed at Northern Arizona University (J. Wittke, T. Bunch), and Dhofar 979 was determined to be an olivine–pigeonite ureilite.
Dhofar 979 contains wormy graphiteOpaque form of carbon (C) found in some iron and ordinary chondrites and in ureilite meteorites. Each C atom is bonded to three others in a plane composed of fused hexagonal rings, just like those in aromatic hydrocarbons. The two known forms of graphite, α (hexagonal) and β (rhombohedral), have Click on Term to Read More
between grains and within olivineGroup of silicate minerals, (Mg,Fe)2SiO4, with the compositional endpoints of forsterite (Mg2SiO4) and fayalite (Fe2SiO4). Olivine is commonly found in all chondrites within both the matrix and chondrules, achondrites including most primitive achondrites and some evolved achondrites, in pallasites as large yellow-green crystals (brown when terrestrialized), in the silicate portion Click on Term to Read More
, and does not exhibit evidence of a significant degree of carbon–silicateThe most abundant group of minerals in Earth's crust, the structure of silicates are dominated by the silica tetrahedron, SiO44-, with metal ions occurring between tetrahedra). The mesodesmic bonds of the silicon tetrahedron allow extensive polymerization and silicates are classified according to the amount of linking that occurs between the reductionOxidation and reduction together are called redox (reduction and oxidation) and generally characterized by the transfer of electrons between chemical species, like molecules, atoms or ions, where one species undergoes oxidation, a loss of electrons, while another species undergoes reduction, a gain of electrons. This transfer of electrons between reactants Click on Term to Read More
/smelting processes (FeO + C = Fe + CO) typically seen in other ureilites. Smelting is usually apparent as an increase in free Fe-metal content, a decrease in carbonElement commonly found in meteorites, it occurs in several structural forms (polymorphs). All polymorphs are shown to the left with * indicating that it been found in meteorites and impact structures: a. diamond*; b. graphite*; c. lonsdalite*; d. buckminsterfullerene* (C60); e. C540; f. C70; g. amorphous carbon; h. carbon nanotube*. Click on Term to Read More
content through loss of CO, and an increase in iron carbide content. Notably, this ureilite does not have the hardness observed in other ureilites. Dhofar 979 has a reduction value of R1, which could be consistent with either formation at great depth, where higher pressures inhibit the smelting reaction, or formation at lower temperatures. It was also shown that the pristine graphite in this ureilite has not been converted to diamondOne of the naturally occurring forms of carbon found in meteorites. Each C atom is bonded through covalent sp3 hydrid orbitals to four others. The strength of the C-C bonds makes diamond the hardest naturally occurring substance (according to the Mohs scale) in terms of resistance to scratching. There are Click on Term to Read More
, a transformation which typically occurs through impact shock forces while in proximity to the surface.
A synopsis of current models for ureilite formation is presented on the Kenna
page. The specimen of Dhofar 979 shown above is a 2.03 g partial slice. The photo below shows the complete Dhofar 979 mass in situ
Photo courtesy of Mike Farmer—Mike’s Meteorites and Tektites
The magnified images shown below, courtesy of John Kashuba, show yellowish, translucent olivines forming 120° triple junctions (left), along with crystals of scarce FeNi-metal between silicate grain boundaries (right). The bottom photo is an excellent petrographic thin sectionThin slice or rock, usually 30 µm thick. Thin sections are used to study rocks with a petrographic microscope.
micrograph of Dhofar 979, shown courtesy of Peter Marmet.
Photos courtesy of John Kashuba
click on image for a magnified view
Photo courtesy of Peter Marmet
